Cooling machine

: Description: Single cylinder cooling machine is one of the important equipment in the rotary kiln system. Clinker from rotary kiln makes material exchange heat with air through cylinder and cools material below 200℃. Meanwhile it improves clinker quality and grindablity. Taking air after cooling material to kiln as secondary circulating air can improve heat efficiency of kiln....

+86-513-88755311 88755027

Single cylinder cooling machine is one of the important equipment in the rotary kiln system. Clinker from rotary kiln makes material exchange heat with air through cylinder and cools material below 200℃. Meanwhile it improves clinker quality and grindablity. Taking air after cooling material to kiln as secondary circulating air can improve heat efficiency of kiln.

Characteristic

The single cylinder cooler that Jiangsu Pengfei Group manufactures has a compact, reasonable and easy structure, high heat efficiency, low maintance cost, a saving total equipment investment and high operating effiency.

Technical

Model	Speed r/m	Yield t/h	Reducer	Electric machine
Model	Speed r/m	Yield t/h	Reducer	Model	Power (kw)
φ1.8×20m	5.44	5-7	JZQ750-I-1Z	J03-180M-4	22
φ2×20m	4.54	7	JZQ750-I-1Z	Y180-4	22
φ2×22m	4.54	7-8.5	JZQ750-I-1Z	Y180-4	22
φ2.2×22m	0.56-5.57	12	ZL85-15-I	YCT280-4A	30
φ2.2×22m	5.49	8.5	JZQ750-II-1Z	Y180L-4	22
φ2.2×22m	5.49	8.5	JZQ750-II-2Z	Y180L-4	22
φ2.5×22m	3.5	14	ZL100-35.5-I	YR280M-6	55
φ2.5×22m	2.5-4.5	12-14	ZL100-15-I	YCT315-4B	45
φ2.5×25m	3.5	14	ZLH100-35.5-I	YR280M-6	55
φ2.5×25m	1.54-4.54	15-18	ZL100-15-I	YCT355-4A	55
φ2.8×28m	1.35-3.91	15-18	JH320C-SW-40	YTSP280S-4	75
φ3×28m	2-4	17	ZL115-15-II	YCT355-4B	75
φ3×30m	3.056	18.5	ZL115-15-I	JS115-6	75
φ3×32m	3.056	21.5	ZL115-15-II	Y315M-6	90
φ3×36m	3.10	23	ZL115-15-II	JS115-6	75
φ3.2×36m	2.74-4.67	28	主ZL130-15-I 辅 ZL50-14-II	主YCTD355-4B 辅 Y180L-6	132 15
φ3.2×36m	0.66-4.93	28	主JH450C-SW-35.5 辅 ZL50-14-I	主Z4-225-31 辅 Y180L-6	132 15
φ3.2×36m	4.17	28	主NZS955-40II 辅ZL42.5-15-II	主Y315S-4 辅 Y132M-4	110 7.5
φ3×38m	3.14	27	主ZSY500-50-V 辅 ZL180-20-II	主Y315L1-4 辅 Y160L-6	160 11
φ3.2/3.8/3.2×33m	3.29	30-35	ZL130-15-II	Y315L2-6	132
φ3.4×40m	1.54—4.47	30-32	ZL130-15-II	YCTD355-4B	132
φ3.5×36m	2.73	30-33	主JH450C-SW-40 辅 ZL50-14-I	主YR315M1-6 辅 Y180L-6	132 15
φ3.6×40m	3.28-1.09	34	主ZL130-16-I 辅 ZL42.5-11-I	主JZS2-11-1 辅Y160M-6	160 7.5

label:单筒,冷却机,单筒,冷却机,
